ProScale General Purpose LCD, V3

The General Purpose Readout has a full feature set of user programmable options and functions.
This Readout has single button operation for Absolute vs Incremental measurements, Data Send, Offsets and built in functions like Upper/Lower Limit and Go/NoGo measurements. It has an external connector for DC power in, Programmable Signal out and External Key input. The General Purpose Readout operates on 1 CR123 Lithium battery or 12-24VDC. SPC (Digimatic) output is standard and it is ready for a ProRF wireless transmitter.



In stock
SKU
700-1600-235
$219.00
Product or Custom Design Question

The General Purpose Readout has a full feature set of user programmable options and functions.
This Readout has single button operation for Absolute vs Incremental measurements, Data Send, Offsets and built in functions like Upper/Lower Limit and Go/NoGo measurements. It has an external connector for DC power in, Programmable Signal out and External Key input. The General Purpose Readout operates on 1 CR123 Lithium battery or 12-24VDC. SPC (Digimatic) output is standard and it is ready for a ProRF wireless transmitter.


Features:

  • Battery Operation: 1 CR123 Lithium battery typically lasts up 6-7 months
  • DC Operation: 12-24 VDC
  • LCD Readout: Low power LCD with Auto Off/On
  • Large, easy-to-read: .75 in (20mm) characters
  • Displays: decimal inches, fractions, millimeters, or centimeters
  • Five Operation Keys: Power, Units, Datum, Plus, Minus
  • Six Function Keys: ABS/INC measurements, Data SEND, and 4 special function keys
  • ProRF: Wireless Data Transmitter ready
  • Easy mounting: from behind or through case.
  • Programmable Datum: use Datum key for zero or other value.
  • Special Functions: Go/NoGo, Upper/Lower limit, measurement Sum, Min, Max, Ave.
  • Scaling: Programmable Linear scaling factor.
  • Lock-Out: Front panel keys and Readout programming
  • RoHS compliant:  Lead Free Product
  • MADE IN USA

Specifications:

  fractions inch mm cm
Display Range ± 399 63/64 ± 999.999 ± 9999.99 ± 999.999
Resolution 1/16, 1/32 or 1/64 .1, .01 or .001 .1 or .01 .1, .01 or .001
Repeatability 1/64 .001 .01 .001
Operating Power 1 CR123 Battery  (or equivalent) or 12-24 VDC
Output  SPC (Digimatic®) and a programmable open collector signal
Dimensions 4.5 x 3.5 x 1.5 in. (115 x 90 x 40 mm)
Current Part Number  700-1600-235
Current Firmware version 3.300
User Manual Quick Start Manual
Full User Manual Quick Start Manual Data Sheet (All Read Outs)
User Manual
2D Drawing

ProScale Readout keys Primary Functions

ProScale Readout keys - Secondary Functions

User Manual Quick Start Manual
3D STEP 3D IGES
