ProScale Panel Mount LCD, V3
CURRENT INVENTORY FOR THIS READOUT IS VERY LIMITED. MORE COMING LATE JANUARY 2022.
The In-Panel LCD Readout is is a popular choice for OEM products. It’s ideal for in-panel or control box mounted applications. The Encoder, battery / DC power connections and signal outputs are located on the back side of the Readout for easy access in the panel or control box environment. The Readout is sized for a 1/4 DIN cut-out.
Product or Custom Design Question
- Battery Operation: 1 CR123 Lithium battery lasts up to 12 months
- DC Operation: 12-24 VDC
- LCD Readout: Low power LCD with Auto Off/On
- Large, easy-to-read: .5 inch (12.7 mm) characters
- Displays: decimal inches, fractions, millimeters, or centimeters
- Five Operation keys: Power, Units, Datum, Plus, Minus
- Easy mounting: In a panel or control box up to .5in thick with 1/4 DIN cutout
- Programmable Datum: use Datum key for zero or other value
- Scaling: Programmable Linear scaling factor.
- Lock-Out: Front panel keys and Readout programming
- RoHS compliant: Lead Free Product
- MADE IN USA
|Display Range||± 399 63/64||± 999.999||± 9999.99||± 999.999|
|Resolution||1/16, 1/32 or 1/64||.1, .01 or .001||.1 or .01||.1, .01 or .001|
|Operating Power||1 CR123 Battery (or equivalent) or 12-24 VDC|
|Output||SPC (Digimatic®) and a programmable open collector signal|
|Dimensions||4.125 x 4.125 x 1.16 in. (105 x 105 x 30 mm)|
|Current Part Number||700-1600-435|
|Current Firmware version||3.2xx
